Oil Free Compressors
RSVT315
Oil Free. Official BAOFN specifications, backed by the only OEM warranty on BAOFN units in South Africa.
Key specifications
- Motor
- 315 kW
- Outlet
- DN125
- Weight
- 6500 kg
- Dimensions
- 4200x2200x2370
Catalogue specifications
| Model | RSVT315 |
|---|---|
| Motor Power (kW) | 315 |
| Outlet Size | DN125 |
| Machine Weight (kg) | 6500 |
| Dimensions LxWxH (mm) | 4200x2200x2370 |
| Noise (dB) | 80 ±2 |
Operating options
| Pressure | Flow |
|---|---|
| 7 bar | 58.5 m3/min (2065.9 CFM) |
| 8.5 bar | 55 m3/min (1942.3 CFM) |
| 10 bar | 49.5 m3/min (1748.1 CFM) |
Quote this model
Tell us the duty for this model and we will come back with a quote. Prefer the general form? Open contact.
Datasheet
Spec-sheet PDFs are not published on this site yet. Request the datasheet by email and we will send the official sheet for RSVT315.
Need RSVT315 sized for the duty?
Tell us pressure, flow and hours. We will confirm the catalogue fit and come back within one working day.
