Desiccant Dryers
PE1690
Dryers. Official BAOFN specifications, backed by the only OEM warranty on BAOFN units in South Africa.
Key specifications
- FAD
- 48 m3/min
- Connection
- DN 100
- Power
- 21 kW
- Weight
- 2280 kg
Catalogue specifications
| Type | PE1690 |
|---|---|
| FAD | 48 m3/min |
| Dimensions LxWxH (mm) | 2359 x 1085 x 2702 |
| Pressure Drop | 0.17 bar |
| Inlet/Outlet Connection DN | 100 |
| Weight (kg) | 2280 |
| Power | 21 kW |
| Prefilter | PF 2FC |
| After Filter | PF 2FS |
Quote this model
Tell us the duty for this model and we will come back with a quote. Prefer the general form? Open contact.
Datasheet
Spec-sheet PDFs are not published on this site yet. Request the datasheet by email and we will send the official sheet for PE1690.
Need PE1690 sized for the duty?
Tell us pressure, flow and hours. We will confirm the catalogue fit and come back within one working day.
